| Seats | 2 Seats | 4 Seats (1 Front 1 Rear) | 4 Seats | 6 Seats (2 Front 1 Rear) | 6 Seats | 8 Seats (3 Front 1 Rear) |
|---|---|---|---|---|---|---|
| Length/Width/ Height (m) | 2.4/1.4/2 | 2.8/1.4/2 | 3.1/1.4/2 | 3.5/1.4/2 | 3.9/1.4/2 | 4.3/1.4/2 |
| Wheelbase (m) | 1.7 | 1.7 | 2.4 | 2.4 | 3.1 | 3.1 |
| Ground Clearance (mm) | 150-495 | |||||
| Turning Radius(m) | 3.4 | 3.4 | 4.5 | 4.5 | 5.6 | 5.6 |
| Body Material | Automotive engineering material | |||||
| Chassis | Front axle floating suspension system, rear axle high-strength leaf spring, floating and telescopic hydraulic dampers | |||||
| Motor Power | 3kw | 4kw | 5kw | 6.3kw | 7kw | 7+kw |
| Electronic Control | Yingboer Controller | |||||
| Battery Pack Capacity | Lithium Battery Pack: 48V / 72V(100Ah-150Ah) or Lead-acid Battery Pack: 48V / 72V(100Ah-150Ah) | |||||
| Rated Voltage (v) | 110-240V | |||||
| Drive Mode | Rear-wheel drive or 4-wheel drive | |||||
| Braking Mode | Four-wheel-drum brake or Four-wheel hydraulic disc brakes | |||||
| Maximum Climbing Gradient | 20-30% | |||||
| Maximum Speed | 30-45 (km/h) | |||||
| Charging Time (h) | 8-9 | |||||
| Range | 70-80km | |||||
| Curb Weight(kg) | 450 | 470 | 510 | 530 | 590 | 610 |
| Rated Passenger Capacity | 2 | 4 | 4 | 6 | 6 | 8 |
| Electromagnetic Brake | YES | |||||
| Ingress Protection | IP65/IP67 | |||||
| Customizable Options | Project 113 Customization | |||||
